Gigabit Fiber Optic Media Converter With 9k Byte Super Data Packet

Product Categories

Fiberroad Technology Co., Limited

Contact Now

Name: Gigabit Fiber Optic Media Converter With 9k Byte Super Data Packet
Brand: Fiberroad
Price: 1 USD

Place of Origin : China

Brand Name : Fiberroad

MOQ : 10pcs

Packaging Details : Standard neutral or brand packing

Delivery Time : 2-3 workdays

Payment Terms : 100% T/T advance

Supply Ability : 5000pcs/Month

Model Number : FR-1501XX

Certification : CE

Product name : Fiber Optic Media Converter

Mode : Single mode , Multi mode

Data rate : 10/100Mbps

Port : RJ45

Flow Control : Full Duplex ,Half duplex

Wavelength : 850nm/1310nm/1550nm

Price : Pls send request details

Contact Now

Gigabit Fiber Optic Media Converter With 9k Byte Super Data Packet transmission By store and forwarder mode

Quick Details

Multi-mode 850nm / 1310nm 10 / 100M Fiber Optic Media Converter 1-Fx to 1 RJ45
Auto-adaptation 10Mbps and 100Mbps, convenient for network updating.
With low-temperature-rise chip, no need of cooling system, realization of flow control, decrease of broadcast storm.
With famous brand optical-electronic-integration module providing excellent optical and electrical properties to ensurereliable data transmission and long working life ﹡ Speed 10/100M.
Supporting broadcast filtering, address auto-learning and auto-updating, and store-and-forward operating mechanism.
Supporting full-duplex flow control or half-duplex back pressure working pattern, along with Auto-negotiation.
Single RJ-45 electrical port NIC/HUB, auto cross-identification, link to computer network cards or switches or HUB.
Supporting the switches to choose between 10/100Mbps store-and forward and straight-through transmission pattern(distinct).
Supporting 1600byte super data packet transmission.
dynamic data transmission and full/halfduplex, data rate.
With more than 50, 000 hours MTBF, complying with telecom operating standard.
Ultra low power dissipation(< 2.5W, Input:AC140 ~ 260V), low heat, long-time stable work.
Supporting choosing optical ports from dual fiber(MM), dual fiber(SM), single fiber(SM).

Technical Parameter Description:

Technical Parameter:
Access Method:	10/100Mbps
Standard:	IEEE802.3 , IEEE802.3u, IEEE802.3x, IEEE802.1q, IEEE802.1p, IEEE802.1d
Wavelength:	850nm/1310nm/1550nm
Distance:	Dual Fiber MM : 2Km Dual Fiber SM : 10/20/30/50/80Km Single Fiber SM : 20/40/60Km CAT5 : 100m
Conversion Method:	Media Conversion, Store-and-Forward/straight through
MAC Address Table:	1 K
Buffer Size:	1Mbit
Flow Control:	Duplex : flow control ; Half duplex : back pressure
Time Delay:	Store-and-Forward : 9.6us , Straight-through : 0.9us
BER:	<1/1000000000
LED Indicator Lamps:	TP 100 , FX 100 , FX LINK/ACT, TP LINK/ACT, , FDX, POWER
Power Supply:	DC5V 1A (external power) , AC220 0.5A /DC-48( internal power )
Power Dissipation:	<2.5W
Operating Temperature:	0 ~ 50 ℃
Humidity:	5%~90%
Storage Temperature:	-40~ 70 ℃
Dimension:	25mm (H)* 70mm (W)* 93mm (D)

Order information:

Gigabit Fiber Optic Media Converter With 9k Byte Super Data Packet
